Integration Blueprint: Modular Pixel Walls & Tunnels with R3
The R3 36 LED Matrix Light is a compact 6×6 RGBW led matrix panel for modular pixel walls and tunnels. Start with DMX512 (4/12/144ch), then scale to Art-Net/sACN on a dedicated VLAN as arrays grow. Each head draws 300 W—budget +20% headroom per circuit and maintain airflow (−10–50 °C, IP20). Clean H/V splicing speeds installs; house-style macros keep looks consistent. As a factory manufacturer, we support bulk orders, OEM/ODM customization, and compliance packs per PO so integrators ship the same showfile city to city.
System Design at a Glance
Consistent looks, quick installs, predictable power—built for integrators and venue owners.
Pixel strategy: start small, scale clean
Begin with 4–6 panels to frame a booth or selfie wall; expand to 8–16+ matrix panels for immersive walls/tunnels. The square cabinet keeps the led matrix display symmetrical as you grow.
Angles & audience comfort
Aim panels 5–10° upward to add depth and minimize glare. Keep blinder hits ≤2–3 s and just above eye level. A light haze helps matrix led lights render crisp beams without fogging photos.
Rig shapes that install fast
Use H/V splicing to build arches, tunnels, and rectangular walls without re-rigging. Uniform flight-case foam and labeled looms shorten install/strike and improve repeatability from city to city.
Control Topologies That Scale
From DMX512 rooms to pixel-mapped walls on Art-Net/sACN.
DMX512 baselines (rooms & quick shows)
- 4ch: instant macros on small desks
- 12ch: simple zones with minimal programming
These modes deliver reliable rgb led panel looks for day-one openings or tight turnovers.
144ch for pixel-level mapping
When you need per-cell chases and brandable graphics, patch 144ch. Treat the wall like a mini matrix display and reuse showfiles across venues.
Art-Net/sACN for larger arrays
- Separate VLAN for lighting control traffic
- Nodes/Mergers near the rig; distribute universes cleanly
- Switching: enable IGMP Snooping, set QoS, keep lighting on its own broadcast domain
- Addressing discipline: reserve IP blocks, document universe→port maps, export patch sheets
Showfile discipline (reusability wins)
Standardize color-cal presets, dimmer curves, and cue naming. Lock time-based macros to BPM/timecode so your led arrays feel identical from site to site.
Power & Thermal Planning
- Per head: 300 W nameplate → budget +20% headroom per circuit/string
- Distribution: spread strings across phases; keep home-runs short; label both ends
- Environment: −10–50 °C, IP20 indoor; maintain airflow paths and dust checks
- Cablecraft: right-angle power, short DMX jumpers, strain relief at the panel
Commissioning Checklist (Copy/Paste)
- Verify 0–100% linear dimming matches desk profile; tweak low-end as needed
- Test stepless strobe rates; set shutter/ISO pairs for house cameras
- Program house-style macros: wave, rainbow, burst, checker
- Patch audit: confirm 4/12/144ch addressing blocks & universe assignments
- Network sanity: ping nodes; use unicast Art-Net/sACN where appropriate
- Loss-of-signal behavior: set safe defaults/blackout rules
- Export: save showfile, patch sheet, and network diagram to the venue’s ops drive
Need templates? Ask for our Patch Sheet CSV and Network Diagram PNG to speed handover.
Spec Block (RFP-Ready)
| Item | R3 36 LED Matrix Light |
|---|---|
| LED Source | 36 × 8W RGBW (4-in-1) |
| Control | DMX512, Auto, Master/Slave, Sound |
| DMX Maps | 4ch / 12ch / 144ch |
| Size / Weight | 50 × 50 × 12 cm / 6.8 kg |
| Pack Options | 55 × 55 × 15 cm (≈8 kg GW); 57 × 57 × 31 cm (≈17 kg GW) |
| Splicing | Horizontal & Vertical (walls, arches, tunnels) |
Procurement — Bulk · Customization · OEM/ODM
- Bulk tiers & pallets: EXW/FOB/CIF supported; pallet maps on request for consolidated shipping
- Customization (OEM/ODM): logo/silkscreen, macro preset packs, flight-case foam, cable looms, barcode & color-band labels—built by the factory manufacturer
- Compliance per PO: CE/RoHS/EMC documentation and aging-test media issued against your purchase order
- Spares & SLA: recommend 5–10% spare heads and quarterly PM; we can match your integrator SLA
Example BOMs (Starter → Scale)
- Framed Booth (4–6 panels): R3 ×4–6, node (2–4 universes), short DMX jumpers, right-angle power leads, compact haze
- Venue Wall (8–12 panels): R3 ×8–12, Art-Net/sACN node set, labeled looms, truss clamps, dual haze lines
- Traveling Tunnel (16+ panels): R3 ×16–20, merged universes, VLAN-isolated switch, flight-case pairings, spare kit
Maintenance & Uptime
Keep a simple PM checklist: face clean, fan inlets clear, connectors inspected, patch & firmware confirmed. A five-minute pass per head prevents hours of show-time triage and keeps your led grid uniform on camera.
FAQ — For Integrators & Venue Owners
How many R3 panels should I start with for a permanent wall?
Begin with 8–12 for a small venue wall; tunnels often start at 12–16+. Splice H/V to grow a coherent led matrix display over time.
Do I need a pixel server on day one?
Not necessarily. Run DMX512 in 4ch/12ch for basic rooms; step up to 144ch and Art-Net/sACN when you need per-cell mapping and timeline sync.
What’s the safe power plan for a 12-panel wall?
12 × 300 W = 3.6 kW nameplate; add ≥20% headroom (≈4.3 kW). Distribute strings per phase, keep home-runs short, and label your matrix panels.
