N3 RGBW Pixel Moving Beam Bar with 43CH Pixel Control
Regular price
$420.00
Sale price
$420.00
Regular price
Unit price
Overview
Tax-free and free shipping to the US, EU, and most regions in 7–14 days.
Every stage lighting product is inspected by our QC team before dispatch.
All eligible products include a 1-year warranty, giving you added confidence for professional use.
Get support with product selection, setup questions, shipping updates, and order-related assistance from our team.
Payment Method
What's in the box
User Manual- 1 × N3 RGBW Pixel Moving Beam Bar
- 1 × Power Cable
- 1 × Safety Cable
- 1 × User Manual
Services and Benefits
In Stock Fast Tax-Free Shipping
$420.00
10 RGBW Pixels. Motorized Movement. Full Creative Control.
The StarshineLights N3 is a professional RGBW pixel moving beam bar with ten 30W RGBW 4-in-1 LED cells and a motorized Y-axis. It combines movement, color, pixel effects, dimming, strobe, and built-in effect playback in one indoor stage fixture. Use 7CH for movement and global RGBW output, 13CH for dimming, strobe, presets, speed, and background controls, or 43CH for independent RGBW programming of all ten LED cells. DMX512, RDM, Auto, Sound Active, and Master/Slave support both programmed show control and standalone operation.
10×30W / 10×40W RGBW Pixel Output
Two Output Options: Choose between 10×30W and 10×40W RGBW 4-in-1 LED configurations according to your stage and effect requirements.
Ten RGBW LED Cells: Ten individually programmable RGBW cells form a powerful linear pixel-effect engine.
Full RGBW Color Mixing: Red, green, blue, and white channels provide saturated colors, blended tones, and white output.
32-Bit Linear Dimming: Smooth 0–100% dimming supports controlled fades and intensity transitions.
Independent Pixel Programming: In 43CH mode, every RGBW LED cell can be programmed individually.
Pixel Control: The N3 supports independent ten-cell RGBW pixel control, with the original manual documenting the 10×30W RGBW configuration.
Motorized Y-Axis Movement
Motorized Beam Positioning: The complete LED bar moves along the Y-axis for dynamic directional effects.
Dedicated Motor Speed Control: DMX provides separate movement-position and movement-speed channels.
Moving Linear Effects: Combine motorized movement with RGBW color, chases, gradients, strobe, and pixel patterns.
DMX Fixture Reset: A dedicated reset channel supports controller-based fixture recovery.
Adjustable Motor Parameters: Motor behavior can also be adjusted through the fixture menu.
43CH Independent Pixel Control
10 Independent RGBW Pixels: Each LED cell receives separate red, green, blue, and white control.
40 Dedicated Color Channels: Ten pixels × four RGBW channels provide detailed color programming.
43 Channels Total: Y-axis movement, movement speed, 40 pixel-color channels, and reset provide detailed fixture control.
Pixel Chases: Create sequential color movement across the bar.
Custom Gradients: Build alternating colors, gradients, mapped effects, and animated pixel patterns.
Pixel-Mapped Effects: 43CH mode is designed for chases, gradients, and pixel-mapped RGBW effects across all ten LED cells.
Three DMX Profiles for Flexible Programming
7CH Mode: Motorized movement plus global RGBW control for compact and efficient programming.
13CH Mode: Adds master dimming, strobe, built-in effects, speed, and background-color functions.
43CH Mode: Provides independent RGBW control of all ten pixels for advanced pixel programming.
DMX512: Designed for conventional professional lighting-console programming and synchronized show control.
RDM: Supports compatible remote fixture discovery and addressing functions.
Specs
General
Brand: StarshineLights
Model: N3
Product Type: RGBW Pixel Moving Beam Bar
Fixture Type: Pixel-Controlled Y-Axis Moving Beam / Strobe Effect Light
Power Options: 10×30W / 10×40W
Housing: Black Metal
IP Rating: IP20
Intended Environment: Dry Indoor Use
Operating Temperature: −30°C to 50°C
Electrical
Input Voltage: AC 100–240V
Frequency: 50/60Hz
LED Configuration: 10×30W / 10×40W RGBW
Rated Power (10×30W): 320W
Rated Input Power (10×40W): To Be Confirmed
Light Source
Light Source: 10 × 30W / 10 × 40W RGBW 4-in-1 LEDs
LED Quantity: 10
LED Power: 30W or 40W Per Cell
Available Versions: 10×30W / 10×40W
Color System: RGBW
Pixel Quantity: 10 RGBW Cells
Independent Pixel Control: Yes
Pixel Control Mode: 43CH
Dimming: 32-Bit Linear
Dimming Range: 0–100%
Control
DMX Protocol: DMX512
RDM: Supported
DMX Profiles: 7CH / 13CH / 43CH
Pixel Profile: 43CH
Automatic Mode: Yes
Sound Active: Yes
Master/Slave: Yes
Built-In Effects: 127
Fixture Reset: DMX Controllable
Movement
Movement: Motorized Y-Axis
Position Control: DMX Controllable
Motor Speed: Adjustable
DMX Movement Channels: Position + Speed
Factory Motor Parameter: M000–M255
Effects
Strobe: 1–30Hz
Built-In Effects: 127
Main Effects: Beam / Pixel / Strobe / Chase / Gradient / Preset Effects
FAQ
Q: What is the StarshineLights N3, and who is it designed for?
A: The StarshineLights N3 is an RGBW pixel moving beam stage light bar available in 10×30W and 10×40W versions. It combines ten RGBW LED cells, motorized Y-axis movement, pixel control, strobe effects, and DMX512/RDM operation for dry indoor DJ setups, clubs, live stages, event production, and programmed lighting systems.
Q: Should I choose the 10×30W or 10×40W N3?
A: Choose the 10×30W version for standard indoor stage lighting and multi-fixture installations. Choose the 10×40W version when higher LED output and stronger visual impact are preferred. Both versions use ten RGBW cells and share the same N3 moving-beam and pixel-control concept.
Q: Can each of the 10 RGBW pixels be controlled independently?
A: Yes. In 43CH mode, all ten RGBW LED cells can be programmed independently. Each pixel receives separate red, green, blue, and white control, allowing the N3 to create pixel chases, gradients, alternating colors, and custom RGBW sequences.
Q: Which DMX profile should I use: 7CH, 13CH, or 43CH?
A: Use 7CH for simple Y-axis movement and global RGBW control. Choose 13CH when you also need master dimming, strobe, built-in effects, effect speed, and background-color functions. Use 43CH for independent RGBW control of all ten pixels and detailed pixel programming.
Q: Can I use the N3 without a DMX controller?
A: Yes. The N3 supports Auto and Sound Active modes, allowing built-in effects to run without an external DMX console. Sound Active mode responds to audio through the fixture microphone, while DMX control is available when more detailed show or pixel programming is required.
Q: What lighting effects can the N3 create?
A: The N3 combines motorized Y-axis movement with RGBW color, pixel chases, gradients, dimming, and adjustable 1–30Hz strobe effects. It also includes 127 built-in effects, with effect selection and playback-speed control available in 13CH mode.
Q: Does the N3 support DMX512 and RDM?
A: Yes. The N3 supports DMX512 and RDM. DMX512 provides control of movement, RGBW output, strobe, built-in effects, and individual pixels depending on the selected channel profile. Compatible RDM controllers can also use supported remote fixture discovery and addressing functions.
Q: Can multiple N3 fixtures run together?
A: Yes. Compatible N3 fixtures can operate in Master/Slave mode for synchronized standalone playback. Configure one fixture as the master and the others as slaves so linked fixtures can follow compatible fade, pulse, jump, sound-active, dimming, and automatic effects.
Q: Is the N3 suitable for outdoor use?
A: No. The N3 is rated IP20 and is designed for dry indoor use only. It should be protected from rain, water spray, and prolonged humidity. For outdoor installations, choose a stage light bar with an appropriate outdoor IP rating.
Q: What input voltage does the N3 support?
A: The N3 operates on AC 100–240V, 50/60Hz, allowing it to work with common mains-voltage systems in many regions. The documented 10×30W configuration has a rated power of 320W; the exact rated input power of the 10×40W version should be confirmed separately.
Q: What do I need for overhead installation?
A: For overhead use, install the N3 with suitable mounting hardware and an independent safety cable. Disconnect mains power before installation, inspection, cleaning, or maintenance, keep ventilation openings clear, and do not operate the fixture if its housing, cables, connectors, or mounting hardware are damaged.
Q: What comes in the box with the N3?
A: The N3 package includes 1 × N3 RGBW Pixel Moving Beam Bar, 1 × Power Cable, 1 × Safety Cable, and 1 × User Manual. Select the 10×30W or 10×40W version according to the LED output configuration required for your setup.
