SM20 RGB 20W Laser Module | Pro RGB Laser Module for Laser Projectors
Pro-Grade RGB Laser Module for Laser Projectors & Laser Show Systems
If you’re building or upgrading a laser projector for touring, festivals, outdoor installs, or architectural effects, the SM20 is a clean, stable laser module designed for fast integration. This RGB laser module uses all-fiber beam shaping for a crisp spot and consistent projection—ideal for graphics, logos, and long throws where beam quality matters.
Unlike “DIY-only” modules that require custom machining, SM20 focuses on real-world install speed: the module mounts easily, fits most common laser housings on the market, and keeps your build time predictable. If you’re not sure how to install it, we can provide a step-by-step video tutorial so your team can follow along without guesswork.
Color Accuracy & Output That Holds Up in Real Shows
SM20 delivers a true RGB wavelength set—638nm red, 525nm green, and 450nm blue—built for vivid mixing and strong color separation.With <1% RMS power stability over 4 hours, the output stays steady during long events and continuous runtime—important for professional show programming and repeatable cues.
The beam profile is shaped with all-fiber shaping, helping you get a cleaner projection edge and better “readability” for patterns, text, and graphics—especially when paired with an ILDA scanner set.
Fast Modulation for Show Control (Analog 0–5V)
SM20 supports analog modulation designed for show workflows: full power above 2V and laser off below 2V, within an approximate 0.12V–4.95V range.That makes it easy to integrate into typical laser show system builds and control chains.
Whether you’re running cues from software controllers or integrating into a broader rig, this modulation behavior is built to behave predictably—so your brightness curves and fades feel consistent from rehearsal to show day.
Beam & Throw Performance for Projection Work
For projection, divergence and spot size matter. SM20 is rated at 1.0 mrad divergence with an exit spot around 5 × 7 mm (1/e²).At distance, it’s specified at roughly 18 × 20 mm at 10m and 30 × 28 mm at 20m, supporting sharp graphics and efficient scanning.
This makes SM20 a strong fit for laser mapping, logo projection, stage beams, and install scenarios where you need stable geometry and predictable beam spread.
Built for Integration: Compact, Stable, and Easy to Install
SM20 is lightweight, convenient to integrate, and built for stable performance in show environments.The module footprint is 220(L) × 147(W) × 50.5(H) mm, with a light output height of 40 mm, making it easier to plan alignment inside common enclosures.
Easy mounting design; compatible with most mainstream laser projector housings.
If your team hasn’t installed a module before, we provide a clear video tutorial (mounting + wiring + modulation check).
Recommended: keep enclosure airflow aligned with the module’s heat path for best stability.
Specs
Wavelengths
638±5nm / 525±5nm / 450±5nm
Output power (W)
5.6 (R) / 6 (G) / 8.5 (B)
Spot type
All-fiber shaping
Power stability (RMS, 4 hours)
1%
Divergence
1.0 mrad
Exit beam size (1/e²)
5 × 7 mm
Beam size @10m (1/e²)
18 × 20 mm
Beam size @20m (1/e²)
30 × 28 mm
Operating mode
CW
Power input
DC 48V
Module size
220 × 147 × 50.5 mm
Output height
40 mm
Operating temperature
-30°C to 40°C
Warranty
2 years
FAQ
Q: Is SM20 compatible with my laser projector housing?
A:Yes—SM20 is designed for easy integration and can match most common laser housings on the market. If you share your enclosure photos or internal mounting space, we can confirm fit quickly.
Q: Is this an ILDA laser module?
A:SM20 is the RGB laser module itself. Pair it with an ILDA scanner set and controller to build a complete ILDA laser projector system.
Q: Can it be used with Pangolin QuickShow or BEYOND?
A:Yes—when SM20 is integrated into a projector with an ILDA interface and scanners, it can be used in show workflows commonly driven by controllers and software such as Pangolin systems (integration depends on your controller/FB4/laser interface).
Q: How hard is installation?
A:It’s designed to be straightforward: mount, wire power, connect modulation, verify thermal airflow. If you’re not experienced, we provide a video tutorial for step-by-step installation.
Q: What should I do for heat management?
A:Use an enclosure with proper airflow and align the cooling path with the module’s heat path. Avoid blocking vents and keep dust/humidity controlled.
Q: Can I run it continuously at events?
A:Yes—SM20 is specified for stable output with <1% RMS stability over 4 hours and a short preheat time, making it suitable for continuous show use.
Q: What’s the typical use case?
A:Stage lighting, laser projection, outdoor lighting accents, positioning, and other applications that need a compact RGB source.
