X7 Recessed Installation Guide — 20 cm Opening, 18 cm Depth
| Contents | Jump |
|---|---|
| 1. Design Objective | Go to section |
| 2. Layout (6–12 Units) | Go to section |
| 3. Openings & Mounting (20/18) | Go to section |
| 4. Control & Scenes (DMX512 9CH) | Go to section |
| 5. Safety & Compliance | Go to section |
| 6. Maintenance & Operations | Go to section |
| 7. Handover Pack | Go to section |
| 8. Procurement (Bulk / OEM/ODM) | Go to section |
| 9. Bill of Materials | Go to section |
| 10. Case Example (12 m Front) | Go to section |
| FAQ (Collapsible) | Go to section |
| Get the Tech Bundle (CTA) | Go to section |
1) Design Objective: Invisible Hardware, Visible Impact
Guests should see atmosphere—not fixtures. The X7 provides bee-eyes beams, RGBW soft wash, and a green-laser focus in one compact body—true professional DJ laser lights behavior with an architectural finish across clubs, hotel ballrooms, convention halls, and multipurpose rooms.
Specs at a glance: Power 80 W • Voltage AC220V/50 Hz • Control DMX512 (9CH) • Strobe ≤ 20 Hz (short bursts) • Recessed opening 20 cm • Install depth 18 cm • Ceiling height ≥ 3 m • Dimming 0–100% ultra-smooth.
2) Layout Recommendations (6–12 Units)
Coverage Logic
Use an even grid over the dance floor / aisle / stage front for uniform wash and balanced beam geometry. Keep spacing consistent so your laser light show looks symmetrical on camera.
| Room Width (guide) | Units | Layout |
|---|---|---|
| 8–10 m | 6 | 2×3 grid or perimeter focus |
| 10–14 m | 8 | 2×4 grid |
| 14–18 m+ | 10–12 | 2×5 / 2×6 (mirror or alternate) |
Height & Angles
Ceiling ≥ 3 m. Aim slightly above eye line and away from fixed cameras; add a 1–3° shim behind the trim to bias beams without revealing hardware.
Power & Data Runs
- Power: AC220V to each opening, zone grouping with start-up headroom; label each point.
- DMX: One trunk with opto-isolated splitters; terminate properly. Leave an address/ID card by each service hatch.
3) Openings & Mounting (20 cm / 18 cm)
Cutout & Depth
Cut a clean 20 cm opening (round or square to match the trim) and maintain 18 cm minimum depth from finished surface to structural stop for airflow and service clearance.
Service hatch: Always include one adjacent to each opening for safe removal and access.
Flush Finish & Ventilation
- Install so body and trim are coplanar with the ceiling; use black/white trims to match palette.
- Preserve a small plenum airflow path; keep insulation clear of intake/exhaust zones.
Fixings & Safety
Use manufacturer-rated brackets and a secondary safety tether. For gypsum ceilings, reinforce with a ring or backer plate spanning joists.
4) Control & Scenes (DMX512 9CH)
A unified 9-channel personality minimizes cross-console friction and simplifies training—key for operators standardizing laser DJ lights across properties.
Copy-Ready Scene Templates
- Club: higher movement energy, fan beams, short ≤ 20 Hz strobe pops on chorus hits.
- Corporate: low saturation, slow fades, camera-friendly levels.
- Wedding/Banquet: warm-white base (20–40%), green-laser “lock focus.”
Triggers
- Scheduler: daypart automation for open/close.
- GPIO/Relays: tie to venue control or show-control systems.
- Sound-active: low/medium sensitivity for hands-off nights.
Need the map? See the DMX512 9CH channel map.
5) Safety & Compliance
Aim above eye height and away from cameras; validate with a person-height target during commissioning. Avoid sustained strobe in sensitive-audience scenarios; if used, keep bursts short and post signage. Follow local laser regulations; keep printed presets/limits in the venue binder.
6) Maintenance & Operations
- Quarterly service: dust trims/optics, verify fans and cable strain relief, check the safety tether.
- Preset review: refresh palettes/levels seasonally; confirm with the venue’s reference camera profile.
- Inspection log: runtime hours, error codes, showfile version—standardize across locations.
7) Handover Pack (Client Deliverables)
- Construction drawings — openings, depth, power/DMX routes, service hatch detail.
- DMX templates & SOP — 9CH map, Club/Corporate/Wedding presets, strobe etiquette.
- Training checklist — operations, maintenance, safety & signage.
- Compliance inserts — aiming limits, strobe guidance, local policy summary.
8) Procurement, Bulk & Customization (OEM/ODM | Factory)
- Bulk & staged shipping for multi-property rollouts with predictable lead times.
- OEM/ODM options: logo/nameplate, packaging, flightcases; co-branded docs via the manufacturer.
- Factory QC — batch aging, spot checks, compliance sheets included.
- Warranty & SLA — 2-year warranty, optional spare-pool, remote commissioning support.
Explore professional DJ laser lights, core laser DJ lights bundles, and our OEM/ODM & factory program.
9) Bill of Materials (Starter, 6–12 Units)
- X7 recessed kits with trims (6–12 pcs)
- AC220V circuits, breakers, labels
- DMX trunk, opto-splitters, short jumpers, terminators
- Reinforcement rings/backer plates, brackets, safety wires
- Service-hatch hardware & signage
- Optional UPS/rack shelf, patch labels, showfile USB
10) Case Example: 12-Meter Front (8 × X7)
- Rig (30 min): cut/verify openings, mount, daisy-chain power/DMX, address by zone.
- Program (20 min): load Corporate preset, confirm mirror vs alternate geometry, set camera-safe levels.
- Polish (20 min): tune speed curves to BPM; cap strobe at 20 Hz for brief peaks.
- Handover: leave SOP & safety card in the hatch; print the channel map for FOH.
FAQ (Collapsible)
Will the recessed build overheat the unit?
What ceiling height do I need?
Can we run without a console?
How many units for a ballroom?
Do you offer bulk pricing and OEM/ODM?
Service after recessing?
Do I need fire-rated enclosures or special approvals?
