F23 DMX512 Dual-Prism Moving Head Beam Light 295W for Events
Regular price
$610.00
Sale price
$610.00
Regular price
Unit price
Overview
Tax-free and free shipping to the US, EU, and most regions in 7–14 days.
Every stage lighting product is inspected by our QC team before dispatch.
All eligible products include a 1-year warranty, giving you added confidence for professional use.
Get support with product selection, setup questions, shipping updates, and order-related assistance from our team.
Payment Method
What's in the box
User Manual- 1 × F23 295W Moving Head Beam Light
- 1 × Power Cable
- 1 × DMX Signal Cable
- 1 × User Manual
Services and Benefits
In Stock Fast Tax-Free Shipping
$610.00
<
High-Output 295W Beam Performance
The 295W light source delivers up to 15,000 lumens and 7,500K cool white output for bright professional stage lighting. Its narrow 0°–4° beam angle creates crisp aerial shafts for concerts, clubs, weddings, and live productions, while electronic focus sharpens beam and gobo patterns through DMX control. The compact housing is easy to transport, install, and integrate with other stage lights.
Dynamic Colors, Gobos, and Prism Effects
14-Color Wheel: Fourteen colors plus white create single-color, split-color, and continuous color-wheel effects.
13-Gobo Wheel: Thirteen fixed gobos plus open create aerial textures and projected patterns.
Gobo Animation: Gobo shake, bidirectional wheel rotation, and scrolling effects add motion to stage and event lighting.
Dual Prism System: An 8-facet prism and an 8+16+24-facet compound prism create layered multi-ray effects.
Strobe and Dimming: A 1–11 flashes-per-second strobe and 0–100% mechanical dimming support fades, blackouts, and chases.
Precise DMX512 Control and Movement
16CH DMX Control: The 16-channel DMX512 mode controls pan, tilt, colors, gobos, prisms, focus, dimming, strobe, lamp, and reset functions.
Standalone Modes: Built-in auto programs and sound-active operation work without an external DMX controller.
Wide Pan and Tilt: The moving head offers 540° pan and 270° tilt for broad stage coverage.
16-Bit Positioning: Selectable 8-bit and 16-bit movement resolution supports fast sweeps and precise beam placement.
User-Friendly Display: The English and Chinese menu includes screen reversal, manual testing, system information, and display timeout settings.
Energy-Saving and Stable Operation
Adjustable Lamp Power: Lamp output adjusts when full brightness is not needed.
Half-Power Mode: Power consumption drops by about 50% to reduce heat and extend lamp life.
Efficient Electronics: A power factor up to 0.99 and THD below 20% support efficient professional operation.
Reliable Power System: An electronic ballast and AC/DC switching power supply provide stable output during demanding shows.
Indoor Protection: The IP20-rated housing and overheat protection suit dry indoor stage lighting environments.
Built for Events, Stages, and Venues
Concert Lighting: The intense narrow beam and fast movement suit small and medium concerts and live-music stages.
Wedding Lighting: Color effects, gobos, and rotating prisms enhance wedding venues, ballrooms, and event halls.
DJ Lights: Sound-active operation and dynamic beam effects suit mobile DJs and entertainment companies.
Club Lighting: Fast pan and tilt, strobe effects, and multi-facet prisms create energetic looks for bars and nightclubs.
Professional Installations: The compact fixture integrates with moving head lights and other stage lighting equipment in theaters, studios, and indoor venues.
Specs
General
Model: F23
Product Type: Moving Head Beam Light
DMX Channels: 16CH
Control Modes: DMX512, Auto Program, and Sound-Active
Protection Rating: IP20, Indoor Use
Power & Light Source
Input Voltage: AC 90–220V
Frequency: 50/60Hz
Light Source: 295W
Rated Power: 450W
Luminous Flux: Up to 15,000 lm
Color Temperature: Up to 7,500K
Optical System
Beam Angle: 0°–4°
Focus: Electronic Focus
Dimming: 0–100% Mechanical Dimming
Additional Effects: Seven-Color Effect and Frost Effect
Color & Gobo System
Color Wheel: 14 Colors + White
Color Effects: Split Colors and Bidirectional Wheel Rotation
Gobo Wheel: 13 Gobos + Open
Gobo Effects: Gobo Shake, Scrolling, and Bidirectional Rotation
Prism System
Prism System: Dual Rotating Prism System
Prism Effects: 8-Facet and 8+16+24-Facet Compound Prism
Dimmer & Strobe
Dimming: 0–100% Mechanical Dimming
Strobe Speed: 1–11 Flashes per Second
Movement
Pan Movement: 540°, 8-Bit/16-Bit Resolution
Tilt Movement: 270°, 8-Bit/16-Bit Resolution
Display & Control
Display Languages: English and Chinese
Display Functions: Screen Reversal and Energy-Saving Mode
Lamp Power Control: Adjustable Output with Half-Power Mode
Power Electronics
Power Factor: Up to 0.99
THD: Below 20%
Power Electronics: Electronic Ballast and AC/DC Switching Power Supply
Product Dimensions
Product Size: 28 × 22 × 46 cm
Net Weight: 10 kg
Packaging
Package Size: 54 × 30 × 38 cm
Gross Weight: 12 kg
Operating Environment
Protection Rating: IP20
Recommended Use: Dry Indoor Stage Lighting Environments
FAQ
Q: What is the F23 moving head beam light designed for?
A:The F23 is designed for concerts, weddings, DJ stages, bars, clubs, theaters, studios, event halls, and other dry indoor stage lighting applications.
Q: How bright is the F23 beam light?
A:The fixture produces up to 15,000 lumens from its 295W light source, delivering a bright and focused beam for professional stages and entertainment venues.
Q: What is the beam angle?
A:The F23 provides a narrow 0°–4° beam angle, creating sharp aerial shafts that remain clearly visible when used with stage haze.
Q: Can the F23 operate without a DMX controller?
A:Yes. In addition to 16CH DMX512 control, the fixture includes built-in auto programs and sound-active operation.
Q: How many colors does the fixture provide?
A:The color wheel includes 14 colors plus white. It also supports split-color looks and bidirectional color-wheel rotation.
Q: How many gobos are included?
A:The F23 includes 13 gobos plus an open position, with gobo shake, scrolling, and bidirectional wheel-rotation effects.
Q: What prism effects are available?
A:The dual prism system includes an 8-facet prism and an 8+16+24-facet compound prism. Both prisms can rotate to produce layered multi-beam effects.
Q: Does the fixture include electronic focus?
A:Yes. Electronic focus allows the operator to sharpen the beam and gobo projection remotely through DMX.
Q: What is the pan-and-tilt range?
A:The fixture provides 540° pan and 270° tilt with selectable 8-bit or 16-bit movement resolution.
Q: Does the F23 have an energy-saving mode?
A:Yes. Half-power mode can reduce lamp consumption by approximately 50% when maximum output is not required. The display also supports an energy-saving timeout.
Q: Can the F23 be used outdoors?
A:No. The fixture has an IP20 protection rating and is intended for dry indoor environments. It should not be exposed to rain, moisture, or outdoor weather.
Q: Is the F23 suitable for DJ and club lighting?
A:Yes. Its fast movement, sound-active mode, rotating prisms, gobos, strobe, and color effects make it suitable for DJ lights, club lighting, and mobile entertainment systems.
Q: How are multiple F23 moving head lights addressed?
A:Each fixture uses 16 DMX channels. Typical starting addresses are A001 for the first fixture, A017 for the second, and A033 for the third.
