M24 7×40W RGBW Bee-Eye Zoom Moving Head Light
Regular price
$550.00
Sale price
$550.00
Regular price
Unit price
Overview
Tax-free and free shipping to the US, EU, and most regions in 7–14 days.
Every stage lighting product is inspected by our QC team before dispatch.
All eligible products include a 1-year warranty, giving you added confidence for professional use.
Get support with product selection, setup questions, shipping updates, and order-related assistance from our team.
Payment Method
What's in the box
User Manual- 1 × M24 Moving Head Light
- 1 × Power Cable
- 1 × Mounting Bracket
- 1 × User Manual
Services and Benefits
In Stock Fast Tax-Free Shipping
$550.00
Pixel-Controlled RGBW Bee-Eye Effects with Motorized Zoom
The StarshineLights M24 is a 7×40W RGBW bee-eye zoom moving head light designed for stages, clubs, touring productions, and event lighting. Seven RGBW 4-in-1 LEDs provide saturated color mixing, smooth dimming, layered effects, and individual pixel control, while motorized zoom and a rotating optical system create changing beam shapes and dynamic bee-eye patterns. With 540° pan, up to 270° physical tilt travel, 16-bit positioning, and 23CH, 35CH, or 51CH DMX profiles, the M24 scales from straightforward fixture programming to detailed seven-pixel RGBW control.
7×40W RGBW Bee-Eye Output
Seven RGBW LEDs: Seven 40W RGBW 4-in-1 LED sources provide color mixing and multi-cell bee-eye effects.
RGBW Color Mixing: Independent red, green, blue, and white output supports saturated colors and mixed tones.
Linear Dimming: Master dimming provides smooth adjustment from blackout to full output.
1–25Hz Strobe: Synchronized strobe is supported together with random strobe effects.
Color Temperature Control: DMX includes adjustable color-temperature control.
350W Rated Power: The M24 is rated at 350W and uses seven 40W RGBW 4-in-1 LEDs.
Motorized Zoom and Rotating Lens Effects
Motorized Zoom: Adjust the optical effect from narrower to wider through DMX.
Rotating Optical System: Adds dynamic movement to the seven-lens bee-eye output.
Indexed Lens Positioning: Position the rotating optical system at repeatable indexed values.
Continuous Rotation: Run the optical system continuously in either direction.
Built-In Effects: Static, dynamic, color wash, fade, and pattern functions expand programming options.
51CH Individual RGBW Pixel Control
Seven Independent RGBW Pixels: Each of the seven LEDs can be controlled separately in 51CH mode.
28 Pixel Channels: Channels 24–51 provide four RGBW channels for each LED.
Individual Color Programming: Different colors and intensities can be assigned across the seven LEDs.
Detailed Pixel Effects: Create chases, segmented colors, and multi-cell transitions.
Full Fixture Control: Movement, zoom, rotation, dimmer, strobe, and effects remain available alongside pixel programming.
51CH Pixel Mapping: In 51CH mode, the seven LEDs are mapped as seven independent RGBW pixels.
23CH, 35CH and 51CH DMX Programming
23CH Mode: Compact control of movement, RGBW output, zoom, rotation, dimmer, strobe, and built-in effects.
35CH Mode: Adds finer color and dimmer control plus more detailed foreground/background effect programming.
51CH Mode: Adds independent RGBW control of all seven LEDs.
16-Bit Positioning: Fine pan and tilt channels provide more precise movement control.
DMX Addressing: Fixture starting addresses can be set from 001 to 512.
Specs
Brand
StarshineLights
Model
M24
Product Type
RGBW Bee-Eye Zoom Moving Head Light
Rated Power
350W
Applications
Stage, Club, Touring and Event Lighting
Light Source
7 × 40W RGBW 4-in-1 LEDs
LED Quantity
7
LED Power
40W Each
Color System
RGBW
Dimming
Linear Dimming
Strobe
1–25Hz Synchronized Strobe + Random Strobe
Zoom
Motorized Focus / Zoom
Optical Effect
Rotating Lens / Bee-Eye Optical Effect
Other Effects
Color Temperature, Wash / Fade, Static and Dynamic Effects
Pan
540°
Tilt
Up to 270° Physical Travel
Pan Fine
Yes
Tilt Fine
Yes
Positioning
16-Bit Pan / Tilt
Movement Speed
DMX Adjustable
Protocol
DMX512
DMX Profiles
23CH / 35CH / 51CH
DMX Address
001–512
Master / Slave
Yes
Sound Active
Yes
Sound Sensitivity
0–30
Individual Pixel Control
Yes, in 51CH Mode
Pixel Count
7 RGBW Pixels
Pixel Color Channels
28
Static Effects
Yes
Dynamic Effects
Yes
Display
Color Display
Menu Language
Chinese / English
Display Reverse
Normal / Reverse
Display Mode
60 sec / Always On
Operating Time Display
Yes
Head Temperature Display
Yes
Sensor Monitoring
Pan / Tilt / Focus / Temperature / Fan
Input Voltage
AC 90–240V
Frequency
50–60Hz
23CH Profile
Best for general show programming with compact access to core movement, RGBW, zoom, rotation and effects.
35CH Profile
Best for layered effect programming with fine RGBW / dimmer control and foreground / background effect functions.
51CH Profile
Best for individual pixel programming with independent RGBW control of all seven LEDs.
Rated Power
350W
FAQ
Q: What is the StarshineLights M24 and who is it designed for?
A:The StarshineLights M24 is a 7×40W RGBW bee-eye zoom moving head light designed for stage, club, touring, and event lighting. It combines seven RGBW 4-in-1 LEDs with motorized zoom, rotating optical effects, 540° pan, up to 270° physical tilt travel, and 23CH, 35CH, or 51CH DMX programming.
Q: Can each of the seven RGBW LEDs be controlled independently?
A:Yes. Select 51CH mode for individual pixel control. Channels 24–51 provide separate red, green, blue, and white control for each of the seven LEDs, giving the M24 seven independently programmable RGBW pixels.
Q: Which DMX profile should I use: 23CH, 35CH, or 51CH?
A:Choose 23CH for compact control of movement, RGBW output, zoom, lens rotation, strobe, and built-in effects. Choose 35CH when you want finer color and dimmer control plus more detailed foreground and background effect programming. Choose 51CH when your show requires individual RGBW control of all seven LEDs.
Q: Can the M24 operate without a DMX controller?
A:Yes. The M24 supports Master/Slave and Sound Active operation in addition to DMX512, so a DMX console is not required for every setup. Sound sensitivity can be adjusted from 0–30. The current manual does not list Auto as a selectable run mode, so Auto operation should not be assumed.
Q: Can multiple M24 moving heads operate together?
A:Yes. Multiple M24 fixtures can be addressed and programmed through DMX512 or synchronized using compatible Master/Slave operation. For DMX setups, choose the appropriate 23CH, 35CH, or 51CH profile and assign starting addresses so channel ranges do not overlap unless identical fixture behavior is intended.
Q: What do the motorized zoom and rotating lens effects do?
A:The motorized zoom adjusts the optical effect from narrower to wider through DMX. The rotating optical system can also use indexed positions or continuous rotation in either direction, creating changing bee-eye patterns and movement beyond normal pan and tilt. The current documentation does not specify an exact numerical zoom-angle range.
Q: What types of lighting effects can the M24 create?
A:The M24 combines RGBW color mixing, linear dimming, synchronized and random strobe, color-temperature adjustment, color wash and fade effects, static and dynamic effects, motorized zoom, rotating optics, and individual seven-pixel RGBW programming in 51CH mode. This gives lighting programmers multiple ways to create layered stage and club looks.
Q: How much pan and tilt movement does the M24 provide?
A:The M24 is specified for 540° pan and up to 270° physical tilt travel, with fine pan and tilt channels for 16-bit positioning. The manual notes that active DMX tilt mapping may vary with firmware or calibration, so actual fixture response should be checked before finalizing production showfiles.
Q: Is the M24 waterproof or suitable for outdoor use?
A:The M24 documentation does not list an IP rating. It instructs users to keep the fixture dry and protect it from rain, liquid splash, and prolonged high humidity unless a specific enclosure rating states otherwise. For that reason, the M24 should not be selected or marketed as a waterproof or weatherproof moving head based on the current documentation.
Q: What should I know before installing and powering the M24?
A:Use a properly grounded AC 90–240V, 50–60Hz power supply. For overhead mounting, use appropriately rated mounting hardware and an independent safety cable, keep the ventilation openings clear, and disconnect mains power before installation, inspection, cleaning, or service.
