N5 LED IP65 Outdoor Wall Washer Strobe 420W DMX RDM
Outdoor LED Wall Wash Lighting with IP65 Protection
The N5 is a high-output LED wall washer that doubles as a waterproof strobe bar (IP65) for stages, façades, and event spaces. Its 420W engine and dense array—240 white LEDs + 480 7070 LEDs—deliver uniform wall wash lighting across long spans, then switch instantly to strobe accents for cues and drops. Built for real weather, it works reliably in rain, dust, heat, and cold, making it a versatile outdoor wall washer light for architecture and touring.
Smooth 16-bit Dimming & 1–30Hz Strobe for Stage and Camera
N5 features 16-bit, 0–100% linear dimming for clean fades and camera-friendly looks. Use the broad 1–30Hz strobe range to match musical BPM or create industrial textures in haze; then return to even, streak-free wall washing for scenic scenes and feature walls. From livestream sets to arena shows, the beam stays consistent and flicker-resistant with proper shutter/frame alignment.
DMX512 + RDM Control, 4/11/140 CH for Pixel Chase
Program shows precisely with DMX512, or run auto/sound for quick setups. RDM speeds addressing and diagnostics across large rigs to save onsite time. Choose 4CH for fast shows, 11CH for deeper looks, or 140CH for pixel-style chases (running/marquee), wave effects, and synchronized architectural animations. One fixture scales from plug-and-play to fully show-programmed control.
Metal Build, Wide Temp Range, Daisy-Chain Power/DMX
A metal, black housing and IP65 sealing protect the internals for long deployments. Power in/out and DMX in/out support tidy daisy chains outdoors; add drip loops and weather-rated connectors for best practice. Rated for −30°C to 50°C, N5 is engineered for touring, festivals, plazas, and façade lighting where uptime matters.
Fast Layouts for Facades & Events (Spacing & Circuit Tips)
On a 10–15 m stage, start with 4–6 units along the lip or sides for even wash plus blinder hits. On 25–40 m façades, use 3–5 m spacing to build a clean base; tighten spacing for higher lux or more dramatic pixel chase effects. For power planning, budget ~1.8–2.0A @ 220–240V per unit (or 3.5–4.2A @ 100–120V) and leave headroom per circuit; then daisy-chain signal and power to reduce setup time.
Specs
Voltage
AC 100–240V, 50/60 Hz
Power
420W
LED Configuration
240 × white LEDs + 480 × 7070 LEDs
Control Modes
DMX512, Auto, Master–Slave, Sound; RDM supported
DMX Channels
9 / 23 / 72CH
Dimming
16-bit, 0–100% linear
Ingress Protection
IP65 (outdoor)
Built-in Effects
Running (marquee) + Strobe
Strobe Rate
1–30 Hz
Working Temperature
−30°C to 50°C
FAQ
Q: Can N5 be both a wall washer and a strobe?
A:Yes. It provides even wall wash lighting and switches to 1–30Hz strobe for musical cues and effects.
Q: Is N5 suitable for outdoor rain and dust?
A:Yes. The IP65 design and metal housing support rain, dust, and −30°C to 50°C operation.
Q: What control options are available?
A:DMX512, RDM, auto, sound, and master–slave. Pick 4/11/140 CH based on show complexity.
Q: Is it camera-friendly for streaming and filming?
A:The 16-bit linear dimming helps reduce banding. Match camera shutter/frame rate if using fast strobe on camera.
